A few months ago, I spent a weekend building out a solver for the Navier-Stokes equations for an incompressible fluid in Rust. I had to brush up on the math needed which I haven't touched since university, but the main goal of the project was to be pushed off the deep end on Rust and emerge a Rustacean. Did I succeed on that front? Maybe. I still have a long way to go on fully grasping Rust (and it's strange yet powerful concepts like ownership) like I do Python or Go, but I feel much more confident in the language.
Anyway, I felt the need to revisit this project and try to make some optimizations. The actual simulation is quite clunky, and the codebase felt messy to me as I lumped everything into main.
Some goals for this were:
- Improve the performance by some measurable metric.
- Along with that, eliminate any major bottlenecks within the solver code.
- Refactor the codebase to seperate the Model from the View as is a staple of good, clean code.
- Apply some more advanced Rust concepts I've read about since initial implementation. (Mainly things i've learned about while reading Klabnik's The Rust Programming Language)
Performance Optimization
The main way I wanted to improve the performance was through how I was allocating memory.
On my initial implementation, I was foolishly allocating 50 new vectors each iteration via .clone() inside loops like so:
// Step 2: Pressure Solve
// Solves the Poisson equation to enforce incompressibility.
fn solve_pressure(&mut self, dt: f64) {
// Implementation of the Jacobi iteration for the pressure solve.
// This is where we calculate divergence and iterate to find p.
let dx = self.dx;
// We can assume density is 1 for simplicity, as it scales the pressure
let rho = 1.0;
// Part 1: Calculate the divergence of the velocity field.
// This is the right-hand side of the Poisson equation.
let mut divergence = vec![0.0; self.nx * self.ny];
for j in 0..self.ny {
for i in 0..self.nx {
let u_right = self.u[self.u_idx(i + 1, j)];
let u_left = self.u[self.u_idx(i, j)];
let v_top = self.v[self.v_idx(i, j + 1)];
let v_bot = self.v[self.v_idx(i, j)];
let d = (u_right - u_left + v_top - v_bot) / dx;
divergence[self.p_idx(i, j)] = d;
}
}
// Part 2: Iteratively solve for pressure using the Jacobi method.
// We repeat this loop to let the pressure values settle.
let mut p_new = self.p.clone();
let num_iterations = 50; // More iterations = more accuracy
for _ in 0..num_iterations {
for j in 1..self.ny - 1 { // We only solve for interior pressure points
for i in 1..self.nx - 1 {
let p_right = self.p[self.p_idx(i + 1, j)];
let p_left = self.p[self.p_idx(i - 1, j)];
let p_top = self.p[self.p_idx(i, j + 1)];
let p_bot = self.p[self.p_idx(i, j - 1)];
let d = divergence[self.p_idx(i, j)];
// This is the discretized Poisson equation rearranged for p_i,j
let p_updated = (p_right + p_left + p_top + p_bot - d * dx * dx) / 4.0;
p_new[self.p_idx(i, j)] = p_updated;
}
}
// Update the pressure field for the next iteration
self.p = p_new.clone();
As one might imagine, this creates quite a performance bottleneck as we allocate a new Vec each loop. I did some digging around the web and found the idea of double buffering --> we keep two persistent buffers and swap in between them. This forum post was helpful as was some asking around Gemini.
To actually implement this, I introduced a few "previous" state buffers (p_prev, u_prev, and v_prev), as well as a scratch buffer (divergence) to my FluidGrid struct. So now, instead of calling .clone() each loop, these "previous" bufferes are reused without allocating any extra memory.
To handle the swapping between them, I used std::mem::swap combined with copy_from_slice to copy data without reallocation.
Here is how it looks with the changes:
// Step 2: Pressure Solve
// Solves the Poisson equation to enforce incompressibility.
fn solve_pressure(&mut self, _dt: f64) {
// Implementation of the Jacobi iteration for the pressure solve.
// This is where we calculate divergence and iterate to find p.
let dx = self.dx;
// Part 1: Calculate the divergence of the velocity field.
// This is the right-hand side (RHS) of our Poisson equation.
for j in 0..self.ny {
for i in 0..self.nx {
let u_right = self.u[self.u_idx(i + 1, j)];
let u_left = self.u[self.u_idx(i, j)];
let v_top = self.v[self.v_idx(i, j + 1)];
let v_bot = self.v[self.v_idx(i, j)];
let d = (u_right - u_left + v_top - v_bot) / dx;
let idx = self.p_idx(i, j);
self.divergence[idx] = d;
}
}
// Part 2: Iteratively solve for pressure using the Jacobi method.
// We repeat this loop to let the pressure values settle.
// Copy current p to p_prev to start with a good guess
self.p_prev.copy_from_slice(&self.p);
let num_iterations = 50; // More iterations = more accuracy
for _ in 0..num_iterations {
for j in 1..self.ny - 1 { // We only solve for interior pressure points
for i in 1..self.nx - 1 {
let p_right = self.p[self.p_idx(i + 1, j)];
let p_left = self.p[self.p_idx(i - 1, j)];
let p_top = self.p[self.p_idx(i, j + 1)];
let p_bot = self.p[self.p_idx(i, j - 1)];
let d = self.divergence[self.p_idx(i, j)];
// This is the discretized Poisson equation rearranged for p_i,j
let p_updated = (p_right + p_left + p_top + p_bot - d * dx * dx) / 4.0;
let idx = self.p_idx(i, j);
self.p_prev[idx] = p_updated;
}
}
// Update the pressure field for the next iteration
mem::swap(&mut self.p, &mut self.p_prev);
}
}
As stated, I wanted a way to measure this improvement on performance. To do this meaningfully, I put in a "slow" mode that I could toggle during runtime. I kept the .clone() logic alongside and measured (in microseconds) the time to compute each frame of the sim and print to stdout. I created a simple toggle switch (B on the keyboard during simulation). After doing that, I ran the simulation and switched back and forth. Below, you can see quite a decrease in compute time per frame:
Optimized mode: true
Frame time: 104.042µs
Frame time: 106.041µs
Frame time: 98.625µs
Frame time: 105.917µs
Frame time: 98.5µs
Frame time: 103.125µs
Frame time: 110.209µs
Frame time: 99.833µs
Frame time: 104.083µs
Optimized mode: false
Frame time: 175.208µs
Frame time: 168.875µs
Frame time: 168.708µs
Frame time: 182.708µs
Frame time: 187.125µs
Frame time: 171.875µs
Frame time: 171.417µs
Frame time: 172.25µs
Based on this, we can extract a bit of concrete metrics on how much we increased our performance through double buffering. We got a roughly 69% increase in performance (or a roughly 41% reduction in compute time per frame). Pretty cool stuff!
- Optimized Average: ~103.38 µs per frame
- Unoptimized Average: ~174.77 µs per frame
Decoupling the Visualization from the Simulation
The secondary objective of all this was to clean up the code bit and seperate concerns. I moved the rendering/view code to its own structure.
The FluidRenderer struct purely handles coloring the speed gradient, and drawing the two modes I currenlty have implemented: vector field and scalar heatmap.
This now keeps the FluidGrid struct to handling just the physics simulation / solving aspect of things.
Final Organization Tweaks
As I was moving the FluidRenderer logic into its rightful struct, I realized I should probably just conform to the MVC pattern and move everything to its own file, so I did that and added the following:
grid.rs--> to houseFluidGridrenderer.rs--> to houseFluidRenderer
Closing
There is still quite a lot I want to do with this solver to get it more to a water/smoke sim state, both in performance and visually. I would love to explore using rayon to parallelize it in a better way to decrease the compute time per frame even more.
We are currently using semi-lagrangian advection with bilinear interpolation, which is stable, but the trade off is that we are smoothing out a lot of the interesting swirls and details that make water and smoke sims so interesting to generate. Some topics I've read a bit about but need to find a way to implement include: vorticity confinement, advecting a density field, and maybe swap out the semi-lagrangian advection for MacCormack advection to get a sharper edge on the fluid.
Also, now that we are optimized, I'd like to see how it handles higher resolutions like 100x100.
Maybe next weekend!
